Features:

• Dual lines LED display
• Unit display
• Auto / Manual function
• PID auto temperature control
• Selectable two thermocouple types ( J or K )
• Selectable two temperature scales ( °C or °F )
• Selectable six alarm modes
• Zero trigger output modes ( Zero cross )
• Fuse break indicator
• Thermocouple break and inverse detect

Specifications:

• Power input: 220Vac ± 15 %
• Power frequency: 50 / 60Hz
• Power consumption: 2W ( each module )
• Input impedance: 16M Ω
• Output wattage: 3600W, 15A / 240Vac
• Storage temperature: -20 ~ 70 °C
• Work temperature: 0 ~ 50 °C
• Work humidity: 10 ~ 80 % RH ( non-condensing )
• Control accuracy: ± 0.25 % FS
• Measure accuracy: ± 0.25 % FS
• K type thermocouple range: 0 ~ 700 °C ( 0 ~ 1200 °F )
• J type thermocouple range: 0 ~ 500 °C ( 0 ~ 900 °F )
