Features:

• Multiple Touch-off signal options ( AC220 / 110 / DC24 / Switch type )
• Multiple output voltage options ( AC220 / 110 / DC24 / Relay / MOS Relay )
• Time display is adjustable to the first digit after the decimal point
• Stopwatch can be either accumulative or countdown
• Three optional control modes
• Optional pressure retaining mode
• MOS Relay extension of working life
• Mechanical Relay ( up to 600 mA ) is optional

Specifications:

• Panel measurement: 50 × 176 mm
• Display: 7-Section tube 0.4 × 4 × 2
• Power switch: manual dial type
• Input power: AC220 ( 50 / 60Hz )
• Trigger voltage: ( Must jump JP ), AC110 ( 50 / 60Hz ), AC220 ( 50 / 60Hz ), DC24, Switch ( DC24 )
• Output power: ( must jump JP ), AC110 ( RELAY / electronic switch 4VA ), AC220 ( RELAY，2A / electronic switch 600 mA ),DC24 ( RELAY / electronic switch 4W ), RELAY－2A / electronic switch－600 mA ( either one )
• Keys: 5 keys ( select / confirm, manual output, plus, minus, time setting )
• Function display lamps: A / B mode lamp, OPEN lamp, SIGNAL lamp, pressure retaining lamp, manual output lamp
